125 kg Tilting Washer Extractor

The 48040 F7Z runs a 25 HP single-motor inverter drive with a wider wash speed range of 20 to 40 RPM and extraction up to 664 RPM at 300 G-force, giving operators more flexibility across different fabric types. RinSave technology paired with large cylinder perforations cuts water and energy use per rinse cycle without sacrificing wash quality. Ten liquid chemical injection ports with programmable bath temperatures support consistent dosing across all formula types. The MilTouch VGA touchscreen displays live formula time, machine status, and fault diagnostics, reducing downtime and operator error.

Brand : Milnor

Model Number :  48040 F7Z

Capacity :  275 lb (125 kg)

Specifications

  • Capacity275 lb (125 kg)
  • Cylinder Volume42 cu ft (1188 L)
  • Wash Speed20 to 40 RPM
  • Extraction Speed200 to 664 RPM
  • Machine Dimensions (W x D x H)82.5 x 93.88 x 98.25 in (2096 x 2385 x 2496 mm)
  • Cylinder Diameter x Depth48 x 40 in (1219 x 1016 mm)
  • Motor25 HP (18.5 kW)
  • Distribution Speed66 RPM
  • Extraction G-Force300 G
  • Water Pressure Required10 to 75 psi (0.68 to 5.1 bar)
