ADC AD-50V industrial dryer, 50 lb capacity, showing tumbler depth and exhaust connection

23 Kg Drying Tumbler

The ADC AD-50V is a 23 Kg capacity industrial on-premise dryer built to handle the consistent demands of mid-volume laundry operations in healthcare, hospitality, and institutional settings. With a tumbler volume of 18.3 cu ft and a 3/4 hp motor, it delivers reliable throughput across varied linen types. Airflow of 750 cfm at 60 Hz via an 8" exhaust connection ensures fast and efficient moisture removal. The AD-50V is available in gas, electric, and steam heat variants with electric oven options of 20, 24, and 30 kW.

Brand : ADC

Model Number : AD-50V

Capacity : 23 Kg

enquire now Download brochure

Specifications

Maximum Capacity (dry weight)23 Kg
Tumbler Depth37-1/2" / 95.3 cm
Tumbler Motor3/4 hp / 0.56 kW
Door Opening Diameter21-1/2" / 54.61 cm
Airflow (Gas/Electric, 60 Hz)750 cfm / 21.2 cmm

Tumbler Diameter32-3/4" / 83.2 cm
Tumbler Volume18.3 cu ft / 518 L
Cabinet Dimensions (W x D x H)34-1/4" x 48-3/4" x 72"
Gas Heat Input150,000 Btu/hr / 37,800 kcal/hr
Exhaust Connection (Gas)8" / 20.3 cm

23 Kg Drying Tumbler
