ADC AD-120 on-premise industrial dryer  showing large tumbler and exhaust connection detail
ADC AD-120 on-premise industrial dryer  showing large tumbler and exhaust connection detail
ADC AD-120 on-premise industrial dryer  showing large tumbler and exhaust connection detail

54 Kg Drying Tumbler

The ADC AD-120 is a 54 Kg capacity industrial on-premise dryer built for high-throughput laundry facilities in hospitals, large hotels, and industrial laundries. With a 38.10 cu ft tumbler volume and 2,150 cfm airflow at 60 Hz, it delivers fast, consistent drying across bulky and heavy linen loads. The 14" exhaust connection and electric oven options of 72 and 75.6 kW make it adaptable to varied facility power and ventilation setups. Available in gas, electric, and steam heat variants, with steam consumption rated at 450 lb/hr.

Brand : ADC

Model Number :  AD-120

Capacity :  54 Kg

Specifications

  • Maximum Capacity (dry weight)54 Kg
  • Tumbler Depth42-1/8" / 107.00 cm
  • Tumbler Motor3/4 hp / 0.56 kW
  • Door Opening Diameter31-3/8" / 79.69 cm
  • Airflow (Gas/Electric, 60 Hz)2,150 cfm / 60.9 cmm
  • Tumbler Diameter44-5/8" / 113.35 cm
  • Tumbler Volume38.10 cu ft / 1,078.87 L
  • Cabinet Dimensions (W x D x H)48-5/8" x 62-1/2" x 86-7/8" (gas)
  • Gas Heat Input375,000 Btu/hr / 94,498 kcal/hr
  • Exhaust Connection (Gas)14" / 35.56 cm
