59 kg Washer-Extractor

Image SP-130 delivers high-speed extraction in freestanding suspended design. Advanced IWT touch-screen controller with Image Washer Software (IWS) enables programmable wash patterns in five languages. Single-motor inverter drive with variable frequency control reduces energy consumption while enabling high G-force extraction. Solid cast-iron bearing housing with dual-lip seals ensures long life. Large oversized door opens 165° for easy loading. 5-degree lean-back cylinder design reduces balance problems and extends shaft/bearing life. Optional steam or electric heating with 1 or 5-compartment supply dispensers. Ideal for small to medium hospitality, healthcare, and on-premise laundries requiring energy-efficient, reliable performance without expensive foundation work.

Brand : Image

Model Number :  SP-130

Capacity :  130 lbs (59 kg)

Specifications

  • Capacity130 lbs (59 kg)
  • Basket Depth627mm (24.7")
  • Door Opening Diameter509mm (20") / Height: 820mm (32.3")
  • Motor7.5 HP (10 kW), single, with variable frequency inverter
  • Distribution Speed64 RPM
  • Extract 2767 RPM (350-G)
  • Drain101.6mm (4") capacity 1,256 L/min (332 gal/min)
  • Electrical Power36 kW standard
  • Basket Diameter1067mm (42")
  • Basket Volume0.56 cu. ft. (20 L)
  • Machine Dimensions (W x D x H)1370mm x 1615mm x 1803mm (53.9" x 63.6" x 71")
  • Wash Speed36 RPM
  • Extract 1360 RPM (80-G)
  • Water Inlets1" (Hot, Cold, Additional)
  • Net Weight1,183 lbs (537 kg)
