Forenta 822SBSP Single Buck Press with Sleeve Pleaters
The Forenta 822SBSP is a single buck shirt finishing press with integrated sleeve pleaters, designed for complete shirt finishing from a single stationary position in hotel, institutional, and commercial garment finishing operations. The stationary vacuum buck keeps the shirt firmly in place while the operator dresses it entirely from one position, eliminating repositioning time and improving throughput consistency. Sleeve pleaters can be turned on or off directly from the colour touch screen, which also provides self-diagnostics, easily adjustable time cycles, and a production rate indicator for real-time performance monitoring.
Brand : Forenta
Model Number : 822SBSP
Specifications
- Steam Inlet1/2" NPT
- Recommended Steam Pressure115 to 125 PSIG / 793 to 862 kPa
- Compressed Air3/8" NPT
- Recommended Air Pressure85 PSIG / 586 kPa
- Shipping Weight1690 lb / 767 kg
- Steam Outlet1/2" NPT (total of 4 outlets)
- Steam Consumption86 lb/hr / 39 kg/hr / 2.5 BHP
- Air Consumption per Shirt1.8 cu ft / 51 L (at 85 PSIG)
- Electrical Connection208 to 240V / 460V, 3PH, 50/60Hz, 5.5 to 5.6 kW
- Water Connection (spray)1/4" NPT
